Brand Name:
AT
Model Number:
AT32F403ARGT7
Contact Us
AT32F403ARGT7 PIN To PIN Alternative M3 STM32F411RET6 STM32F103RET6 STM32F103RET6 STM32F103RCT6 STM32F103RBT6
AT32F403ARGT7 PIN To PIN Alternative M3 STM32F411RET6 STM32F103RET6 STM32F103RET7 STM32F103RGT7 STM32F103RGT6 STM32F103RCT6 STM32F103RBT6 STM32F103R8T6 Software hardware is completely compatible
1. High compatibility: compatible with Sxx32F103 pins & highly compatible with software
2.M4 main frequency 240MHz (with FPU/DSP), RAM up to 224KB
3.AT32F403ARC/VC can replace the Sxx103RE/VE project just because of insufficient RAM
4. Rich peripherals: I2Cx3, SDIO x 2, SPI/I2S (full duplex) x 4, CANx2, UARTx8, 32-bit Timer, SPIM can be connected to high-speed SPI NOR Flash
5. Built-in sLib function: unique security & secondary development function
6. High computing power, one can replace multiple
7. Support wide operating temperature range (-40-105 degrees)
8. Support small size package: QFN48 6x6mm
Hot sell
STM32F103VET6 | STM32F427ZGT6 | STM32F105ZDT6 | STM32F030G4U6 | STM32F070F6U6 |
STM32F103VCT6 | STM32F427ZIT6 | STM32F105ZET6 | STM32F030G6U6 | STM32F070F8U6 |
STM32F103C8T6 | STM32F427ZKT6 | STM32F105ZFT6 | STM32F030G8U6 | STM32F070G4U6 |
STM32F103RCT6 | STM32F427IGH6 | STM32F105ZGT6 | STM32F030G4U6 | STM32F070G6U6 |
STM32F103RBT6 | STM32F427IIH6 | STM32F105ZIT6 | STM32F030G6U6 | STM32F070G8U6 |
STM32F103T4U6 | STM32F427IKH6 | STM32F101T4U6 | STM32F030G8U6 | STM32F070G4U6 |
STM32F103T6U6 | STM32F407RET6 | STM32F101T6U6 | STM32F030K4U6 | STM32F070G6U6 |
STM32F103T8U6 | STM32F407RGT6 | STM32F101T8U6 | STM32F030K6U6 | STM32F070G8U6 |
STM32F103TBU6 | STM32F407RKT6 | STM32F101TBU6 | STM32F030K8U6 | STM32F070K4U6 |
STM32F103C4T6 | STM32F407VET6 | STM32F101C4T6 | STM32F030C4U6 | STM32F070K6U6 |
STM32F103C6T6 | STM32F407VGT6 | STM32F101C6T6 | STM32F030C6U6 | STM32F070K8U6 |
STM32F103CBT6 | STM32F407VKT6 | STM32F101C8T6 | STM32F030C8U6 | STM32F070C4U6 |
STM32F103R4T6 | STM32F407ZET6 | STM32F101CBT6 | STM32F030R8U6 | STM32F070C6U6 |
STM32F103R6T6 | STM32F407ZGT6 | STM32F101R4T6 | STM32F207RCT6 | STM32F070C8U6 |
STM32F103R8T6 | STM32F407ZKT6 | STM32F101R6T6 | STM32F207RET6 | STM32F070R8U6 |
STM32F103RBT6 | STM32F407VEH6 | STM32F101R8T6 | STM32F207RGT6 | STM32F105RBT6 |
STM32F103RDT6 | STM32F407VGH6 | STM32F101RBT6 | STM32F207RKT6 | STM32F105RCT6 |
STM32F103RET6 | STM32F407VKH6 | STM32F101RCT6 | STM32F207VCT6 | STM32F105RDT6 |
STM32F103RFT6 | STM32F407IEH6 | STM32F101RDT6 | STM32F207VET6 | STM32F105RET6 |
STM32F103RGT6 | STM32F407IGH6 | STM32F101RET6 | STM32F207VGT6 | STM32F105RFT6 |
STM32F103RIT6 | STM32F4071KH6 | STM32F101RFT6 | STM32F207VKT6 | STM32F105RGT6 |
STM32F103RKT6 | STM32F405RET6 | STM32F101RGT6 | STM32F207ZCT6 | STM32F105RIT6 |
STM32F103V8T6 | STM32F405RGT6 | STM32F101RIT6 | STM32F207ZET6 | STM32F105RKT6 |
STM32F103VBT6 | STM32F405RKT6 | STM32F101RKT6 | STM32F207ZGT6 | STM32F105V8T6 |
STM32F103VDT6 | STM32F405VGT6 | STM32F101V8T6 | STM32F207ZKT6 | STM32F105VBT6 |
STM32F103VFT6 | STM32F405VKT6 | STM32F101VBT6 | STM32F207IET6 | STM32F105VCT6 |
STM32F103VGT6 | STM32F405ZGT6 | STM32F101VCT6 | STM32F207IGT6 | STM32F105VDT6 |
STM32F103VIT6 | STM32F405ZKT6 | STM32F101VDT6 | STM32F207IKT6 | STM32F105VET6 |
STM32F103VKT6 | STM32F405VGH6 | STM32F101VET6 | STM32F427VET6 | STM32F105VFT6 |
STM32F103ZCT6 | STM32F405VKH6 | STM32F101VFT6 | STM32F427VGT6 | STM32F105VGT6 |
STM32F103ZDT6 | STM32F205VCT6 | STM32F101VGT6 | STM32F427VIT6 | STM32F105VIT6 |
STM32F103ZET6 | STM32F205VET6 | STM32F101VIT6 | STM32F427VKT6 | STM32F105VKT6 |
STM32F103ZFT6 | STM32F205VGT6 | STM32F101VKT6 | STM32F427ZET6 | STM32F105ZCT6 |
STM32F103ZGT6 | STM32F205VKT6 | STM32F101ZCT6 | STM32F205ZGT6 | STM32F101ZFT6 |
STM32F103ZIT6 | STM32F205ZCT6 | STM32F101ZDT6 | STM32F205ZKT6 | STM32F101ZGT6 |
STM32F030C8T6 | STM32F205ZET6 | STM32F101ZET6 | STM32F070F4U6 | STM32F101ZIT6 |
STM32F030F4U6 | STM32F030F6U6 | STM32F030F8U6 | STM8S003F3P6 | STM32L151VCT6 |
Sxx Series | Sxx Part | Core | CPU | DSP/FPU | Flash | SRAM | AT32 Series | AT32 Part | Core | CPU | DSP/FPU | Flash | SRAM |
Sxx32F401 | CBU6 | M4 | 84MHz | Yes/Yes | 128K | 64K | AT32F413 | KBU7 | M4 | 200MHz | Yes/Yes | 128k | 16/32/64K |
Sxx32F401 | CCU6 | M4 | 84MHz | Yes/Yes | 256K | 64K | AT32F413 | CCU7 | M4 | 200MHz | Yes/Yes | 256K | 16/32/64K |
Sxx32F401 | RBT6 | M4 | 84MHz | Yes/Yes | 128k | 64K | AT32F413 | RBT7 | M4 | 200MHz | Yes/Yes | 128K | 16/32/64K |
Sxx32F401 | RCT6 | M4 | 84MHz | Yes/Yes | 256K | 64K | AT32F413 | RCT7 | M4 | 200MHz | Yes/Yes | 256K | 16/32/64K |
Sxx32F401 | VCT6 | M4 | 84MHz | Yes/Yes | 256K | 64K | AT32F403A | VCT7 | M4 | 240MHz | Yes/Yes | 256K | 96/224K |
Sxx32F401 | RET6 | M4 | 84MHz | Yes/Yes | 512K | 96K | AT32F403A | RGT7 | M4 | 240MHz | Yes/Yes | 1024K | 96/224K |
Sxx32F401 | VET6 | M4 | 84MHz | Yes/Yes | 512K | 96K | AT32F403A | VGT7 | M4 | 240MHz | Yes/Yes | 1024K | 96/224K |
Sxx32F411 | CCU6 | M4 | 100MHz | Yes/Yes | 256K | 128K | AT32F403A | CCU7 | M4 | 240MHz | Yes/Yes | 256K | 96/224K |
Sxx32F411 | CEU6 | M4 | 100MHz | Yes/Yes | 512K | 128K | AT32F403A | CGU7 | M4 | 240MHz | Yes/Yes | 1024K | 96/224K |
Sxx32F411 | RCT6 | M4 | 100MHz | Yes/Yes | 256K | 128K | AT32F403A | RCT7 | M4 | 240MHz | Yes/Yes | 256K | 96/224K |
Sxx32F411 | RET6 | M4 | 100MHz | Yes/Yes | 512K | 128K | AT32F403A | RGT7 | M4 | 240MHz | Yes/Yes | 1024K | 96/224K |
Sxx32F411 | VCT6 | M4 | 100MHz | Yes/Yes | 256K | 128K | AT32F403A | VCT7 | M4 | 240MHz | Yes/Yes | 256K | 96/224K |
Sxx32F411 | VET6 | M4 | 100MHz | Yes/Yes | 512K | 128K | AT32F403A | VGT7 | M4 | 240MHz | Yes/Yes | 1024K | 96/224K |
