Product Description

Manufacturer: STMicroelectronics
Product Category: Operational Amplifiers - Op Amps
RoHS: Details
Mounting Style: SMD/SMT
Package / Case: SOIC-8
Number of Channels: 2 Channel
Supply Voltage - Max: 12 V
GBP - Gain Bandwidth Product: 4 MHz
Output Current per Channel: 80 mA
SR - Slew Rate: 1.3 V/us
Vos - Input Offset Voltage: 900 uV
Supply Voltage - Min: 2.7 V
Minimum Operating Temperature: - 40 C
Maximum Operating Temperature: + 125 C
Ib - Input Bias Current: 100 nA
Operating Supply Current: 3 mA
Shutdown: No Shutdown
CMRR - Common Mode Rejection Ratio: 60 dB
en - Input Voltage Noise Density: 9 nV/sqrt Hz
Series: TS922A
Packaging: Tube
Amplifier Type: General Purpose Amplifier
Brand: STMicroelectronics
Height: 1.65 mm (Max)
Length: 5 mm (Max)
Operating Supply Voltage: 2.7 V to 12 V
Product: Operational Amplifiers
Product Type: Op Amps - Operational Amplifiers
Subcategory: Amplifier ICs
Supply Type: Single
Technology: BiCMOS
Voltage Gain dB: 106.02 dB
Width: 4 mm (Max)
Unit Weight: 0.017870 oz
