Brand Name:
MICROCHIP
Model Number:
MCP130T-315I/TT
Contact Us
| Product name:MCP130T-315I/TT |  |
| Manufacturer: Microchip | Watchdog Timer: No Watchdog |
| Product Category: Monitoring Circuits | Battery Backup Switch: No Backup |
| Type: Voltage Supervisory | Reset delay time: 350 ms |
| Installation style: SMD/SMT | Supply Voltage - Maximum: 5.5 V |
| Package / Case: SOT-23-3 | Minimum operating temperature: - 40 C |
| Threshold voltage: 3.075 V | Maximum operating temperature: + 85 C |
| Number of monitored inputs: 1 Input | Series: MCP130 |
| Output Type: Active Low, Open Drain | Qualification: AEC-Q100 |
| Manual reset: No Manual Reset | Package: Reel |
| Package: Cut Tape | Package: MouseReel |
| Brand: Microchip Technology | Chip Enable Signal: No Chip Enable |
| Height: 0.95 mm | Length: 2.9 mm |
| Operating supply current: 60 uA | Over voltage threshold: 3.15 V |
| Power Failure Detection: No | Product Type: Supervisory Circuits |
| Factory Packing Quantity: 3000 | Subcategory: PMIC - Power Management ICs |
| Supply Voltage - Min: 1 V | Undervoltage threshold: 3 V |
| Width: 1.3 mm | Unit weight: 8 mg |
