JSD AT91R40008-66AU Integrated Circuits Ic Chips Electronic Component FPGA Board Microcontroller

JSD AT91R40008-66AU Integrated Circuits Ic Chips Electronic Component FPGA Board Microcontroller

Ic Chips AT91R40008-66AU

ARM7TDMI Electronic Component Ic Chips

32 Programmable I/O Lines Ic Chips

Brand Name:


Contact Us

Request A Quote
Product Details
Model Number:
Integrated Circuit
Payment & Shipping Terms
Minimum Order Quantity
Packaging Details
Package: QFP-100
Delivery Time
5-8 work days
Payment Terms
Supply Ability
5k-10k per day
Contact Us
Product Description


• Incorporates the ARM7TDMI® ARM® Thumb® Processor Core – High-performance 32-bit RISC Architecture – High-density 16-bit Instruction Set – Leader in MIPS/Watt – Little-endian – EmbeddedICE™ (In-circuit Emulation)

• 8-, 16- and 32-bit Read and Write Support

• 256K Bytes of On-chip SRAM – 32-bit Data Bus – Single-clock Cycle Access

• Fully-programmable External Bus Interface (EBI) – Maximum External Address Space of 64M Bytes – Up to Eight Chip Selects – Software Programmable 8/16-bit External Data Bus

• Eight-level Priority, Individually Maskable, Vectored Interrupt Controller – Four External Interrupts, Including a High-priority, Low-latency Interrupt Request

• 32 Programmable I/O Lines

• Three-channel 16-bit Timer/Counter – Three External Clock Inputs – Two Multi-purpose I/O Pins per Channel • Two USARTs – Two Dedicated Peripheral Data Controller (PDC) Channels per USART • Programmable Watchdog Timer

• Advanced Power-saving Features – CPU and Peripheral Can be Deactivated Individually • Fully Static Operation – 0 Hz to 75 MHz Internal Frequency Range at VDDCORE = 1.8V, 85°C • 2.7V to 3.6V I/O Operating Range

• 1.65V to 1.95V Core Operating Range

• Available in 100-lead TQFP Package

• -40° C to +85° C Temperature Range 1. Description The AT91R40008 microcontroller is a member of the Atmel AT91 16-/32-bit microcontroller family, which is based on the ARM7TDMI processor core. This processor has a high-performance, 32-bit RISC architecture with a high-density, 16-bit instruction set and very low power consumption. Furthermore, it features 256K bytes of on-chip SRAM and a large number of internally banked registers, resulting in very fast exception handling, and making the device ideal for real-time control applications. The AT91R40008 microcontroller features a direct connection to off-chip memory, including Flash, through the fully-programmable External Bus Interface (EBI). An 8-level priority vectored interrupt controller, in conjunction with the Peripheral Data Controller, significantly improves the real-time performance of the device. The device is manufactured using Atmel’s high-density CMOS technology. By combining the ARM7TDMI processor core with a large, on-chip, high-speed SRAM and a wide range of peripheral functions on a monolithic chip, the AT91R40008 is a powerful microcontroller that offers a flexible and high-performance solution to many computeintensive embedded control applications.

Product name: AT91R40008-66AU JSD AT91R40008-66AU Integrated Circuits Ic Chips Electronic Component FPGA Board Microcontroller 0
Manufacturer: Microchip Product Category: ARM Microcontroller - MCU
RoHS: Details Series: AT91R40008
Installation style: SMD/SMT Package/Case: TQFP-100
Core: ARM7TDMI Program memory size: 0 B
Data bus width: 32 bit ADC Resolution: No ADC
Maximum clock frequency: 75 MHz Number of inputs/outputs: 32 I/O
Data RAM size: 256 kB  Operating supply voltage: 1.8 V
Minimum operating temperature: - 40 C Maximum operating temperature: + 85 C
Package: Tray Height: 1.4 mm
I/O voltage: 3.3 V Interface Type: EBI, USART
Length: 14 mm Moisture Sensitivity: Yes
Number of timers/counters: 10 Timer Processor series: AT91Rx
Product Type: ARM Microcontrollers - MCU Factory Packing Quantity: 90
Supply Voltage - Maximum: 1.95 V Supply Voltage - Min: 1.65 V
