STM8S103K3T6C IC Electronic Components Integrated Circuits IC Chip STM8S103K3T6C

STM8S103K3T6C IC Electronic Components Integrated Circuits IC Chip STM8S103K3T6C

STM8S103K3T6C IC Chip

Integrated Circuit Chips STM8S103K3T6C

8 kB STM8S103K3T6C

Brand Name:


Contact Us

Request A Quote
Product Details
Model Number:
Integrated Circuit
Standard, Tube, Tray, Reel, Sealed Bag.
Payment & Shipping Terms
Minimum Order Quantity
Packaging Details
Package: Standard, Tube, Tray, reel, sealed bag.
Delivery Time
5-8 work days
Payment Terms
Supply Ability
5k-10k per day
Contact Us
Product Description

Features Core


• 16 MHz advanced STM8 core with Harvard architecture and 3-stage pipeline

• Extended instruction set Memories

• Program memory: 8 Kbyte Flash; data retention 20 years at 55 °C after 10 kcycle

• Data memory: 640 byte true data EEPROM; endurance 300 kcycle

• RAM: 1 Kbyte Clock, reset and supply management

• 2.95 to 5.5 V operating voltage

• Flexible clock control, 4 master clock sources – Low power crystal resonator oscillator – External clock input – Internal, user-trimmable 16 MHz RC – Internal low-power 128 kHz RC

• Clock security system with clock monitor

• Power management: – Low-power modes (wait, active-halt, halt) – Switch-off peripheral clocks individually

• Permanently active, low-consumption poweron and power-down reset Interrupt management

• Nested interrupt controller with 32 interrupts

• Up to 27 external interrupts on 6 vectors Timers

• Advanced control timer: 16-bit, 4 CAPCOM channels, 3 complementary outputs, dead-time insertion and flexible synchronization

• 16-bit general purpose timer, with 3 CAPCOM channels (IC, OC or PWM)

• 8-bit basic timer with 8-bit prescaler

• Auto wake-up timer

• Window watchdog and independent watchdog timers Communication interfaces

• UART with clock output for synchronous operation, SmartCard, IrDA, LIN master mode

• SPI interface up to 8 Mbit/s

• I2C interface up to 400 kbit/s Analog to digital converter (ADC)

• 10-bit, ±1 LSB ADC with up to 5 multiplexed channels, scan mode and analog watchdog I/Os

• Up to 28 I/Os on a 32-pin package including 21 high sink outputs

Highly robust I/O design, immune against current injection Unique ID

• 96-bit unique key for each device

Product name:STM8S103K3T6C STM8S103K3T6C IC Electronic Components Integrated Circuits IC Chip STM8S103K3T6C 0
Manufacturer: STMicroelectronics Product Category: 8-bit Microcontroller -MCU
Series: STM8S103K3 Installation style: SMD/SMT
Package/Case: LQFP-32 Program memory size: 8 kB
Data bus width: 8 bit ADC resolution: 10 bit
Maximum clock frequency: 16 MHz Number of inputs/outputs: 28 I/O
Data RAM size: 1 kB Operating Supply Voltage: 2.95 V to 5.5 V
Minimum operating temperature: - 40 C  Maximum operating temperature: + 85 C
Package: Tray Height: 1.4 mm
Interface Type: I2C, SPI, USART Length: 7 mm
Number of ADC channels: 4 Channel Number of timers/counters: 7 Timer
Product Type: 8-bit Microcontrollers - MCU Program Memory Type: Flash
Factory Packing Quantity: 1500 Subcategory: Microcontrollers - MCU
Supply Voltage - Maximum: 5.5 V Supply Voltage - Min: 2.95 V
Width: 7 mm Unit weight: 774 mg
