Electronic Components Ic Chip ADG721BRMZ-REEL7 ADG1419BRMZ-REEL7 IC SWITCH DUAL SPST 8MSOP

Electronic Components Ic Chip ADG721BRMZ-REEL7 ADG1419BRMZ-REEL7 IC SWITCH DUAL SPST 8MSOP

ADG1419BRMZ-REEL7 Ic Chip

Digital Integrated Circuits ADG721BRMZ-REEL7

2 Channel ADG721BRMZ-REEL7

Brand Name:

ADI

Contact Us

Request A Quote
Product Details
Model Number:
ADG721BRMZ-REEL7 ADG1419BRMZ-REEL7
Type:
Integrated Circuit
Package:
8MSOP
Payment & Shipping Terms
Minimum Order Quantity
1000
Packaging Details
Package: 8MSOP
Delivery Time
5-8 work days
Payment Terms
T/T
Supply Ability
5k-10k per day
RELATED PRODUCTS
Contact Us
Product Description

FEATURES 1.8 V to 5.5 V single supply 4 Ω (max) on resistance Low on resistance flatness −3 dB bandwidth >200 MHz Tiny package options 8-lead MSOP 3 mm × 2 mm LFCSP (A grade) Fast switching times tON, 20 ns tOFF, 10 ns Low power consumption (<0.1 μW) TTL/CMOS compatible APPLICATIONS USB 1.1 signal switching circuits Cell phones PDAs Battery-powered systems Communication systems Sample hold systems Audio signal routing Video switching Mechanical reed relay replacement



GENERAL DESCRIPTION The ADG721, ADG722, and ADG723 are monolithic CMOS SPST switches. These switches are designed on an advanced submicron process that provides low power dissipation yet gives high switching speed, low on resistance, and low leakage currents. The devices are packaged in both a tiny 3 mm × 2 mm LFCSP and an MSOP, making them ideal for space-constrained applications. The ADG721, ADG722, and ADG723 are designed to operate from a single 1.8 V to 5.5 V supply, making them ideal for use in battery-powered instruments and with the new generation of DACs and ADCs from Analog Devices, Inc. The ADG721, ADG722, and ADG723 contain two independent single-pole/single-throw (SPST) switches. The ADG721 and ADG722 differ only in that both switches are normally open and normally closed, respectively. In the ADG723, Switch 1 is normally open and Switch 2 is normally closed. Each switch of the ADG721, ADG722, and ADG723 conducts equally well in both directions when on. The ADG723 exhibits break-before-make switching action. PRODUCT HIGHLIGHTS 1. 1.8 V to 5.5 V single-supply operation. 2. Very low RON (4 Ω max at 5 V, 10 Ω max at 3 V). 3. Low on resistance flatness. 4. −3 dB bandwidth >200 MHz. 5. Low power dissipation. CMOS construction ensures low power dissipation. 6. 8-lead MSOP and 3 mm × 2 mm LFCSP.

Product name:ADG721BRMZ-REEL7 Electronic Components Ic Chip ADG721BRMZ-REEL7 ADG1419BRMZ-REEL7 IC SWITCH DUAL SPST 8MSOP 0
Manufacturer: Analog Devices Inc. Product Category: Analog Switch IC
Installation style: SMD/SMT Package/Case: MSOP-8
Number of channels: 2 Channel Configuration: 2 x SPST
On Resistance—Maximum: 4 Ohms Supply Voltage - Min: 1.8 V
Supply Voltage - Maximum: 5.5 V Run Time - Maximum: 20 ns
Idle Time - Maximum: 10 ns Minimum operating temperature: - 40 C
Maximum operating temperature: + 85 C Series: ADG721
Package: Reel
Package: Cut Tape
Package: MouseReel
Height: 0.85 mm
Length: 3 mm Pd-Power Dissipation: 5 uW
Product Type: Analog Switch ICs Factory Packing Quantity: 1000
Subcategory: Switch ICs Supply Current—Maximum: 1 uA
Power Type: Single Supply Switching DC: 30 mA
Width: 3 mm Unit weight: 140 mg
