RS-422 Interface IC DS26C31TM Microcontroller Unit Digital Data Transmission

RS-422 Interface IC DS26C31TM Microcontroller Unit Digital Data Transmission

DS26C31TM Microcontroller Unit

DS26C31TM Interface IC

Digital Data Transmission DS26C31TM

Brand Name:


Contact Us

Request A Quote
Product Details
Model Number:
Integrated Circuit
Payment & Shipping Terms
Minimum Order Quantity
Packaging Details
Package: Reel Package: Cut Tape Package: MouseReel
Delivery Time
5-8 work days
Payment Terms
Supply Ability
5k-10k per day
Contact Us
Product Description

 Description The DS26C31 device is a quad differential line driver


• TTL Input Compatible designed for digital data transmission over balanced

• Typical Propagation Delays: 6 ns lines. The DS26C31T meets all the requirements of

• Typical Output Skew: 0.5 ns EIA standard RS-422 while retaining the low power

• Outputs Will Not Load Line When V characteristics of CMOS. The DS26C31M is CC = 0 V compatible with EIA standard RS-422; however, one

• DS26C31T Meets the Requirements of EIA exception in test methodology is taken(2) . This Standard RS-422 enables the construction of serial and terminal

• Operation From Single 5-V Supply interfaces while maintaining minimal power

• Tri-State Outputs for Connection to System Buses consumption.

• Low Quiescent Current The DS26C31 accepts TTL or CMOS input levels and

• Available translates these to RS-422 output levels. This part in Surface Mount uses special output circuitry that enables the drivers

• Mil-Std-883C Compliant to power down without loading down the bus. This device has enable and disable circuitry common to all 2 Applications four drivers. The DS26C31 is pin compatible to the Differential Line Driver for RS-422 Applications AM26LS31 and the DS26LS31. All inputs are protected against damage due to electrostatic discharge by diodes to VCC and ground.

Manufacturer: Texas Instruments
Product Category: RS-422 Interface IC
Installation style: SMD/SMT
Package / Case: SOIC-Narrow-16
Series: DS26C31T
Function: Driver
Number of Exciters: 4 Driver
Number of receivers: 0 Receiver
Supply Voltage - Maximum: 5.5 V
Supply Voltage - Min: 4.5 V
Operating supply current: 2 mA
Minimum operating temperature: - 40 C
Maximum operating temperature: + 85 C
Package: Reel
Package: Cut Tape
Package: MouseReel
Trademark: Texas Instruments
Operating supply voltage: 5 V
Output current: 150 mA
Output voltage: 1.8 V
Pd-Power Dissipation: 1226 mW
Product: RS-422 Drivers
Product Type: RS-422 Interface IC
Propagation Delay Time: 11 ns
Shutdown: No Shutdown
Factory Packing Quantity: 2500
Subcategory: Interface ICs
Unit weight: 155.100 mg
